Check Valve CV2-08 Mini Hydraulic Power Packs Featuring Remote 4 Metre 2 Button Suitable for Mobile Equipment and Hydraulic Machinery

Basic Information

Brand Name:	Tiandi
Certification:	Ce Iso9001
Model Number:	TDDL-20-02

Minimum Order Quantity:	5sets
Price:	Negotiate
Packaging Details:	Packed In Carton Boxes ,and Then Wooden Pallets
Delivery Time:	25 Work Days
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	5000pcs Per Month

Get Best Price Contact Now

Working Pressure:	18MPa	Mounting Type:	Vertical
Weight:	About 15-18kgs/pc With Each Power Pack	Remote:	4 Pole, 4 Metre 2 Button
Relief Valve:	RV2-08	System Pressure:	18Mpa
Gear Pump:	0.75cc/Rev	Valve Type:	Solenoid
Highlight:	Mini Hydraulic Power Packs with Check Valve , Remote Control Hydraulic Power Packs , Mobile Equipment Hydraulic Machinery Packs

CV2-08 Mini Hydraulic Power Pack with Remote Control

This compact 6-liter hydraulic power unit features a durable steel tank with corrosion-resistant orange finish and includes a 4-meter remote 2-button control. Designed specifically for mobile equipment and hydraulic machinery applications.

Product Overview

This DC compact hydraulic power unit is engineered for dump trailers and various mobile hydraulic systems. It combines a high-pressure gear pump with a reliable DC motor and versatile multi-functional manifold. The compact design delivers stable, efficient performance in demanding applications while the corrosion-resistant steel reservoir ensures durability in harsh outdoor conditions.

Key Features

High Stability: Precision gear pumps and pure copper motors ensure reliable performance with comprehensive factory pressure testing for steady operation under heavy loads
Compact Design: Optimized structure fits seamlessly into limited chassis space of dump trailers for straightforward installation
Corrosion Resistance: 6-liter reinforced steel tank with durable powder coating provides excellent protection against salt spray and surface scratches
Low Maintenance: Innovative manifold block design minimizes external pipe connections, reducing potential for oil leaks
Remote Control: Includes 4-meter 2-button remote for convenient operation

Technical Specifications

Specification	Details
Motor Voltage	DC 12V, 24V, 48V
Motor Power	1.6 kW, 2.1 kW, 3.0 kW
Reservoir Capacity	6 liters (1.6 gallons)
Pump Displacement	0.5cc - 4.2cc/rev (standard: 2.1cc/rev)
Maximum Pressure	18-21 MPa (180-210 bar, 2600-3000 PSI)
Flow Rate	5.0 - 12.0 L/min
Circuit Type	Single-acting (power up hydraulic, return by gravity)
Mounting	Horizontal or vertical
Oil Port Threads	G3/8" or SAE #6 (9/16-18 UNF)
Relief Valve Setting	Adjustable (factory preset: 2500 PSI)
Duty Cycle	S3 (intermittent duty)
Operating Temperature	-25°C to +80°C (-13°F to +176°F)
Recommended Fluid	ISO VG32 or VG46

Applications

Dump trucks and trailers for efficient lifting power and heavy-duty operation

Logistics equipment including forklifts, hydraulic lift platforms, and dock levelers

Sanitation machinery such as road sweepers and waste compactors

Industrial hydraulic stations and crane support systems
