DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter

DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter
DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter
DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter
Basic Information
Place of Origin: Ningbo China
Brand Name: TianDi
Certification: CE,ISO
Model Number: TDDL25032603
Minimum Order Quantity: 20PCS
Price: Negotiation
Packaging Details: Packed in carton boxes ,and then wooden pallets
Delivery Time: 15 work days
Payment Terms: T/T,Western Union,L/C
Supply Ability: 2000pcs per month
Get Best Price Contact Now
Working Pressure: 3000psi Specification: Carton Size 50cm*25cm*30cm
PUMP: 8cc/r Oil Port: G1/4
Valve Voltage: AC380V Tank Size: 4L To 12L
Applicability: Hydraulic Dock Leveler ,Hydraulic Lift, Car Lifter
Highlight:

DC 12V Hydraulic Power Pack

,

2.5Kw Hydraulic Power Pack

,

Lifting platform Hydraulic Power Pack

DC 12V 2.5Kw hydraulic power unit For Aerial Worker Hydraulic Lifter


Basic Specification

  • DC 12V Hydraulic power unit.
  • 2.5kw 12V DC electric motor
  • 2.1cc/rgear pump.
  • metal motor cover.
  • 8L(etc)Round steel tank with drain plug.
  • Hydraulic Power Pack complete with suction filter, return oil pipe and air breather.
  • Mounting: Horizontal Mounting or Vertical.
  • Max pressure: 200 bar.
  • Relief valve: RV2-08.
  • Flow Rate: 2Lto 10L/min.
  • Relief valve and check valve for all standard power unit
  • Oil Port size :M14*1.5


Motor  DC 12V 2.5KW 1450RPM Oil Pump 2.1cc/r
Oil Port M14*1.5 Tank Size 8L
Valve Votage DC 12V Mounting Type Horizontal



Commercial Terms


Minimum Order Quantity: 50pcs
Price: USD175/set
Payment Terms: T/T
Supply Ability 2800 pcs per month
Delivery Time: 25 working days after advance payment received
Packaging Details: Packed in carton boxes ,and then wooden pallets


Drawing


DC 12V 2.5Kw Double Acting Hydraulic Power Pack For Lifting Platform Lifter 0


Product Overview
This 12V DC hydraulic power unit is a highly efficient and compact hydraulic power source designed for small and medium-sized mobile equipment and industrial applications. Driven by a 12V DC motor, combined with a high-performance gear pump and an intelligent safety system, it can stably output up to 200 bar of working pressure to meet the power needs of diverse hydraulic actuators. Its modular design, lightweight structure and flexible installation make it an ideal choice for construction machinery, agricultural equipment, logistics and transport, rescue tools and other fields.

Tag:

hydraulic power pack unit,

industrial hydraulic power units,

compact hydraulic power unit
